15001-20 - Smith 15001-20 MIG Gas Saver Valve 20 SCFH

Technical Overview of the Smith 15001-20 Surge Protector

The Smith Equipment 15001-20 Surge Protector is a precision-engineered pneumatic device designed to mitigate the "accumulator effect" inherent in Gas Metal Arc Welding (GMAW) and Flux Cored Arc Welding (FCAW-G) systems. In a standard MIG setup, when the gas solenoid valve closes at the end of a weld cycle, the pressure within the delivery hose—located between the regulator/flowmeter and the wire feeder—continues to rise until it equalizes with the regulator's static pressure setting. Upon the next trigger actuation, this stored volume of high-pressure gas is released instantaneously, resulting in a flow surge that far exceeds the optimal shielding gas rate.

This surge protector functions as a fixed-orifice flow restrictor, utilizing a calibrated .026-inch aperture to govern gas velocity. It is specifically engineered to deliver a constant flow rate of 20 Standard Cubic Feet per Hour (SCFH) when the upstream pressure is maintained at 30 PSIG. By placing the restriction point immediately at the inlet of the wire feeder or power source, the device effectively decouples the hose capacitance from the arc start, ensuring that gas delivery ramps up smoothly to the design flow rate rather than spiking.

The unit is constructed with standard 5/8"-18 UNF threads, featuring a female inlet and a male outlet. This allows for seamless integration into existing NEMA-standard welding setups without the need for additional adapters. The female side accepts standard inert gas hose nuts (CGA 032 style connections), while the male side threads directly into the solenoid inlet of most industrial wire feeders and compact MIG welders. It is compatible with common shielding gases including pure Argon, Carbon Dioxide (CO2), and Argon/CO2 blends. For optimal performance, the primary regulator must be capable of delivering a steady 30 PSI to the inlet of this device; deviations in inlet pressure will result in proportional changes to the output flow rate due to the fixed nature of the orifice.
