30-15-520 - Smith 30 Series Medium Duty Acetylene Regulator, CGA 520 B-Tank Connection

Industrial Grade Reliability for Portable Acetylene Applications

The Smith 30 Series Acetylene Regulator (Model 30-15-520) represents the pinnacle of medium-duty gas control for portable welding and brazing setups. Engineered by Smith Equipment (a division of Miller Electric), this regulator is specifically configured with a CGA 520 inlet connection, making it the definitive choice for use with "B" size acetylene cylinders (40 cubic feet). It is designed to withstand the rigors of daily industrial use while providing the precision required for delicate soldering and brazing tasks.

Exclusive Sure-Seat™ Technology

One of the primary failure points in gas regulators is the ingress of debris and contamination into the high-pressure seat assembly. Smith has addressed this with their proprietary Sure-Seat™ filtered seat technology. This advanced design incorporates a filtration system directly into the seat assembly, effectively preventing microscopic particles from scoring the sealing surface. This innovation significantly extends the service life of the regulator, reduces maintenance downtime, and lowers long-term repair costs for workshops and field technicians alike.

Robust Construction and Safety

Durability is built into every component of the 30-15-520. The body is forged from solid brass, providing a heavy-duty foundation that resists physical impact. The bonnet is finished with bright nickel plating, offering superior corrosion resistance compared to standard painted or bare brass bonnets. Internally, a highly durable neoprene composite diaphragm replaces the traditional rubber or stainless diaphragms found in lesser units. This composite material offers excellent flexibility for precise pressure control while maintaining the toughness needed to resist rupture.

Safety is paramount when handling acetylene. This regulator features an external relief valve that protects the unit from damage due to inadvertent high-pressure surges. If excessive pressure builds up, the valve automatically releases the pressure and resets, ensuring operator safety. Additionally, the 2.0-inch gauges are protected by shatter-resistant polycarbonate lenses, preventing breakage in rough work environments.

Performance Specifications

This single-stage regulator is rated for a maximum inlet pressure of 400 PSIG and provides a consistent delivery pressure range of 0-15 PSIG. This range is optimized for the safe usage limits of acetylene gas, ensuring that users do not accidentally exceed the critical 15 PSI stability threshold. The color-coded labels further enhance safety by allowing for immediate visual identification of gas service type and performance capabilities.
