SC969 - Smith Gas Axe 6-Foot Extra Heavy Duty Scrap and Demolition Torch

Smith SC969 Gas Axe Extra Heavy Duty Cutting Torch

The Smith SC969 Gas Axe™ is a premier solution for heavy industrial cutting applications, specifically engineered for the rigorous demands of scrap yards, foundries, and large-scale demolition projects. This 72-inch (6-foot) straight cutting torch features a 90-degree head angle and is designed to operate safely and efficiently in severe environments where standard torches fail. The unit boasts an impressive cutting capacity, capable of severing steel up to 24 inches (610 mm) thick when using acetylene, and up to 20 inches (508 mm) with propane or natural gas. This versatility makes it a universal tool for operations utilizing various fuel gas sources, including propylene-based fuels.

Structurally, the SC969 is built for longevity and safety. It utilizes a three-tube construction method that keeps oxygen and fuel gases completely separated until they reach the tip mixer. This design eliminates the risk of mixing tube burnout and significantly increases safety by preventing flashback within the handle. The torch head is manufactured from super-tough, thick-wall manganese bronze, a material chosen for its superior resistance to heat warping and physical damage compared to standard brass components. This is critical in foundry and scrap applications where the torch is often subjected to intense reflected heat and rough handling.

Operational efficiency is enhanced through the use of Smith's proprietary Graf-Tite® soft seat cutting tips. These slip-in tips require only hand tightening to seat, eliminating the need for wrenches and reducing downtime during tip changes. The resilient seat material protects the tip seating area from nicks and ensures a positive seal every time, requiring less replacement than metal-to-metal seat designs. The torch also features stainless steel ball-style valves for precise flame adjustment and positive shut-off, ensuring that gas flow is controlled accurately for optimal cut quality.

The SC969 is designed with maintenance in mind. It includes replaceable hose connections, allowing for quick repairs if the threads become damaged in the field, extending the service life of the torch body. The internal tube supports provide added structural rigidity to the 72-inch length, preventing bending or misalignment of the gas tubes during operation.
